230
3
Press the [Select Source] button.
A source selection window appears.
4
Switch the source using the source selection buttons.
Select a tab to change the button number to display.
Setting a source selection button to the on state
swi
tches the source.
Router Operations (AUX Bus
Control Block)
Press the [RTR MODE] button on the cross-point pad in
the AUX bus control block, turning it on, to switch to
router operation mode.
You can select destinations and sources and perform
ot
her operations using the AUX bus control block in
router operation mode.
For details about assigning destinations, sources, and
l
evels, see “Setting a Router” (page 415).
Selecting a destination and source
Select a destination using the 1st row and 2nd delegation
buttons in the AUX bus control block (router operation
mode) and select a source using the 3rd row and 4th row
cross-point buttons.
The delegation button rows/cross-point button rows may
hav
e different operation modes depending on whether
second delegation mode is enabled/disabled.
The delegation button row/cross-point button row
op
erations are the same as on the AUX bus control block
(AUX bus operation mode).
For details, see “Operation Mode of a Button Row”
(page 87) and “AUX bus control block” (page 89).
The operation mode of the [SHIFT] button in delegation
bu
tton rows/cross-point button rows in the AUX bus
control block (router operation mode) is set in the Home
> Setup > Panel > Router > Delegation Button Assign
menu (19104.51) and Home > Setup > Panel > Router >
Source Table Assign menu (19104.52).
For details about setting delegation button rows, see
“Setting the operation mode of the shift button”
(page 415).
For details about setting cross-point button rows, see
“Setting the operation mode of the shift button”
(page 416).
Selecting a level
Select using the [LEVEL BTN1] button to [LEVEL
BTN4] button assigned to the cross-point pad.
Note
