Input/Output Numbers
The input/output numbers will vary depending on the switcher configuration and system signal format.
Input numbers
1M/E box configuration
1M/E box + cross-point box configuration
2M/E box configuration
Source
number
System signal format
2160P Other than 2160P
Logical box ID Slot number Port number Logical box ID Slot number Port number
1 to 16 1 1 1 to 16 1 1 1 to 16
17 to 32 1 4 17 to 32 1 1 17 to 32
33 to 48 – – – 1 4 33 to 48
49 to 64 – – – 1 4 49 to 64
65 to 80 – – – – – –
81 to 96 – – – – – –
97 to 112 – – – – – –
113 to 128 – – – – – –
129 to 144 – – – – – –
129 to 160 – – – – – –
Source
number
System signal format
2160P Other than 2160P
Logical box ID Slot number Port number Logical box ID Slot number Port number
1 to 16 1 1 1 to 16 1 1 1 to 16
17 to 32 1 4 17 to 32 1 1 17 to 32
33 to 48 2 1 33 to 48 1 4 33 to 48
49 to 64 – – – 1 4 49 to 64
65 to 80 – – – 2 1 65 to 80
81 to 96 – – – 2 1 81 to 96
97 to 112 – – – – – –
113 to 128 – – – – – –
129 to 144 – – – – – –
129 to 160 – – – – – –
Source
number
System signal format
2160P Other than 2160P
Logical box ID Slot number Port number Logical box ID Slot number Port number
1 to 16 1 1 1 to 16 1 1 1 to 16
17 to 32 1 4 17 to 32 1 1 17 to 32
33 to 48 2 1 33 to 48 1 4 33 to 48
49 to 64 2 4 49 to 64 1 4 49 to 64
65 to 80 – – – 2 1 65 to 80
