9. Final Drive Mechanism
9-2
Operational Precautions
Specification
Application gear oil: GEAR OIL SAE 85W-140
Recommended oil: KING MATE serial gear oils
Oil quantity:
HU10U/W 110 c.c. (100 c.c. when replacing)
HU05U 100 c.c. (90 c.c. when replacing)
Torque value
Gear box cover 2.0~2.4kgf-m
Gear oil drain plug 1.0~1.4kgf-m
Gear oil filling bolt 0.8~1.2kgf-m
Special service tools
Inner type bearing puller SYM-6204002
Outer type bearing puller SYM-6204001
Gear box oil seal installer SYM-9120200
Gear box bearing installer SYM-9125500
Bearing (6204) installer SYM-9110400
Bearing (6301) installer SYM-9610000
Bearing (6203/6004UZ) installer SYM-9620000
Drive shaft puller SYM-13000
Puller set SYM-13000-01
Trouble Diagnosis
Engine can be started but motorcycle can not be moved.
y Damaged drive gear.
y Burnt out drive gear.
y Broken drive belt.
Noise
y Worn or burnt gear.
y Worn gear.
Gear oil leaks
y Excessive gear oil.
y Worn or damage oil seal.
