12. Body Cover
12-16
Rear Mudguard
Remove the rear mudguard right side bolt (1 bolt).
Loosen air cleaner mounting bolts, and then
remove the rear mudguard left side bolts (2 bolts).
Remove the rear mudguard.
Installation
Install according to the reverse procedure of
removal.
3 bolts
