14. Steering / Front Wheel / Front Cushion
14-5
Front Wheel
Removal
Disc Brake
Support body bottom and lift front wheel free of
ground with a stand.
Remove the screw, and disconnect speedometer
cable from the gear box.
Remove the wheel axle nut and pull out the axle.
Then, remove the front wheel.
Caution
z Do not operate the front brake lever to avoid
to pressing out the brake lining when
removing the master cylinder.
Drum Brake
Support body bottom and lift front wheel free of
ground with a stand.
Remove the bolts, and disconnect speedometer
cable.
Remove the wheel axle nut and pull out the axle.
Then, remove the front brake panel and the front
wheel.
Wheel axle nut
Screw
Brake cable
Wheel axle nut
Speedomete
r
cable
