6. Cylinder Head / Valve
6-1
Mechanism Illustrations ····················· 6-1
Operational Precautions····················· 6-2
Troubleshooting·································· 6-3
Cylinder Head Removal ······················ 6-4
Cylinder Head Disassembly (HU05U) 6-6
Cylinder Head Disassembly (HU10U/W)
······························································ 6-7
Valve Disassembly······························ 6-9
Cylinder Head Inspection·················· 6-10
Valve Seat Inspection and Service··· 6-12
Cylinder Head Reassembly··············· 6-14
Cylinder Head Installation················· 6-15
Valve Clearance Adjustment············· 6-16
Mechanism Illustrations
6
Home page
Contents
1.0~1.4kgf-m
0.7~1.1kgf-m
1.0~1.4kgf-m
1.8~2.2kgf-m
1.0~1.4kgf-m
