Sym Mio 50 User Manual

16. Electrical Equipment
16-3
Specification
Charging System
Specification
Items
HU10U/W HU05U
Capacity/type 12V4Ah / YTX5L-BS or GTX5L-BS
Charging rate STD: 0.4A/5~10hrs, emergency charging: 4A/0.5hrs
Full charged 13.0~13.2V
Battery
Voltage (20℃)
Under charged 12.3V
Capacity 14V / 3A
Lighting coil resistance (20℃)
Between yellow-white:
0.1~0.8Ω
0.531Ω±20%
Alternator
Charging coil resistance (20℃)
Between white-green:
0.2~1.0Ω
0.722Ω±20%
Leaking current Less 1mA
RPM for starting charging 1800rpm(headlamp ON) 2000rpm(headlamp ON)
Voltage controlled by regulator 13.8±0.5V 13.5±0.5V
Resistance (20℃) 20W5.9Ω
30W 5.9Ω±10% 30W 5.9Ω±10%
Resistor
Resistance (20℃) 5W5Ω
5W 10.2Ω±10% 5W 12Ω±10%
Ignition System
Specification
Item
HU10U/W HU05U
Standard NGK C6HSA (Recommended)
Hot type
───
Cold type
───
Spark plug
Spark plug gap 0.6~0.7 mm
Primary 0.21±10%Ω 0.31Ω±15%
Ignition coil resistance
Secondary (Without
plug cap)
3~5 KΩ 4.0 KΩ±15%
〝“F” Mark
13° BTDC/1700 rpm
13° ° BTDC/2400 rpm
Ignition timing
Full Advanced
degree
22° BTDC/4000 rpm 26° BTDC/8000 rpm
Pulse generator resistance (20℃)
50~200Ω 115Ω±20%
Exciting coil resistance (20℃)
400~800Ω 602Ω±20%
Ignition coil-primary max. voltage
95~400 V
Pulse generator voltage Above 1.7 V
Starting System
Item Specification
type DC TYPE
Starting motor
capacity 0.25 KW
To this chapter contents

Sym Mio 50 Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Rear Brake	Drum
Ignition	CDI
Engine Type	4-Stroke
Cooling System	Air Cooled
Transmission	Automatic
