67096–01
E57978
I31593
Ring Nut
Socket Cap
–AUDIO & VISUAL SYSTEM CIGARETTE LIGHTER ASSY
67–23
2519Author: Date:
2002 CAMRY REPAIR MANUAL (RM881U)
CIGARETTE LIGHTER ASSY
REPLACEMENT
HINT:
COMPONENTS: See page 67–1
1. REMOVE INSTRUMENT PANEL ASH RECEPTACLE ASSY
(See page 71–12)
2. REMOVE CIGARETTE LIGHTER ASSY
(a) Rotate the ring nut counterclockwise to remove it.
(b) Remove the cigarette lighter assy from the instrument
panel ash receptacle assy.
3. INSTALL CIGARETTE LIGHTER ASSY
(a) Properly position the socket at the cutout of the instrument panel ash receptacle assy and insert them.
(b) Install the socket cap.
(c) Rotate the ring nut clockwise from the backside.
