16032–02
Radiator Drain Plug
Water Drain Plug
Radiator Cap
A52575
16–6
–COOLING COOLANT (2AZ–FE)
1825Author: Date:
2002 CAMRY REPAIR MANUAL (RM881U)
COOLANT (2AZ–FE)
REPLACEMENT
1. DRAIN COOLANT
CAUTION:
To avoid the danger of being burned, do not remove the radiator cap while the engine and radiator
are still hot, as fluid and steam can be blown out under pressure.
(a) Remove the radiator cap.
(b) Loosen the radiator plug and drain the coolant.
2. ADD COOLANT
(a) Tighten the radiator drain plug.
(b) Add the engine coolant into the radiator until it overflows.
Capacity:
6.2 liters (6.6 US qts, 5.4 lmp. qts)
HINT:
Press the radiator inlet and outlet hose several times with hard.
If the coolant level gets lower, pour coolant.
Use of improper coolants may damage engine cooling system.
Use ”Toyota Long Life Coolant” or equivalent and mix it with plain water according to the manufactur-
er’s directions.
Using of coolant with includes more than 50 % (freezing protection down to –35C (–31F) or 60 %
(freezing protection down to –50C (–58F)) of ethylene–glycol is recommended but not more than
70 %.
(c) Pour coolant into the radiator reservoir tank until it reaches full line.
(d) Install the radiator cap. ( 1)
(e) Start the engine, and stop shortly. ( 2)
(f) Remove the radiator cap after 10 seconds. Pour coolant if the coolant level is lower. ( 3)
(g) Repeat ( 1), ( 2) and ( 3) until the coolant level remains the same.
To Next Page
