42028–01
D26283
Clutch Start
Switch Assy
42–18
–
CLUTCH
CLUTCH ST
ART SWITCH ASSY
2233
Author:
Date:
2002 CAMRY REP
AIR MANUAL (RM881U)
CLUTCH ST
ART SWITCH ASSY
ON–VEHICLE
INSPECTION
1.
CHECK CLUTCH ST
ART
SYSTEM
(a)
Check
that
the
engine does not start when the clutch ped-
al is released.
(b)
Check
that t
he
engine starts when the clutch pedal is fully
depressed.
If
necessary
, replace the clutch start switch assy
.
770
772
