Page #150 background image
030FQ–01
–SERVICE SPECIFICATIONS BRAKE
03–39
150Author: Date:
2002 CAMRY REPAIR MANUAL (RM881U)
BRAKE
SERVICE DATA
Brake pedal height (from asphalt sheet) 144.1 – 154.1 mm (5.673 – 6.067 in.)
Brake pedal freeplay Pedal free play: 1 – 6 mm (0.04 – 0.24 in.)
Stop lamp switch clearance 0.5 – 2.5 mm (0.020 – 0.098 in.)
Pedal reserve distance from asphalt sheet at 490 N (50 kgf, 110.2 lbf) More than 63 mm (2.48 in.)
Brake booster push rod to piston clearance (w/ SST) Clearance: 0 mm (0 in.)
Front brake pad thickness Standard thickness:
Minimum thickness:
12.0 mm (0.472 in.)
1.0 mm (0.039 in.)
Front brake disc thickness Standard thickness:
Minimum thickness:
28.0 mm (0.433 in.)
26.0 mm (0.039 in.)
Front brake disc runout Maximum disc runout: 0.05 mm (0.0020 in.)
Rear brake pad thickness Standard thickness:
Minimum thickness:
10.0 mm (0.472 in.)
1.0 mm (0.039 in.)
Rear disc brake thickness Standard thickness:
Minimum thickness:
12.0 mm (0.472 in.)
10.5 mm (0.413 in.)
Rear brake disc runout Maximum disc runout: 0.15 mm (0.0059 in.)
Rear brake drum inside diameter Standard inside diameter:
Minimum inside diameter:
228.0 mm (8.976 in.)
230.6 mm (9.079 in.)
Rear drum brake shoe lining thickness Standard thickness:
Minimum thickness:
5.0 mm (0.197 in.)
1.0 mm (0.039 in.)
