–SERVICE SPECIFICATIONS FRONT SUSPENSION
03–33
144Author: Date:
2002 CAMRY REPAIR MANUAL (RM881U)
TORQUE SPECIFICATION
Part Tightened Nâ‹…m kgfâ‹…cm ftâ‹…lbf
Tie rod end lock nut 74 755 55
Steering knuckle x Shock absorber 210 2,141 155
Hub nut 103 1,050 76
Suspension support x Body 80 816 59
Suspension support x Piston rod 49 500 36
Speed sensor wire harness bracket set bolt (w/ ABS) 18.8 192 14
Flexible hose x Shock absorber (w/o ABS) 18.8 192 14
Lower suspension arm set bolt Front side:
Rear side:
200
206
2,039
2,101
148
152
Transverse engine engine mounting insulator set nut 87 887 64
Transverse engine engine mounting insulator x Bracket (MT) 64 653 47
Stabilizer bar bracket x Suspension member 19 194 14
Front suspension member dynamic damper x Front frame assy 29 296 21
Stabilizer bar link set nut 74 755 55
