030EL–01
03–4
–SERVICE SPECIFICATIONS ENGINE CONTROL SYSTEM
115Author: Date:
2002 CAMRY REPAIR MANUAL (RM881U)
ENGINE CONTROL SYSTEM
SERVICE DATA
2AZ–FE
Throttle body
Standard throttle valve opening percentage 60 % or more
Accelerator pedal position sensor
Standard voltage 0.6 – 1.0 V
Camshaft timing oil control valve assy
Standard VVT system is OFF (OCV is OFF)
VVT system is ON (OCV is ON)
Normal engine speed
Rough idle or engine stalled
Intake air flow meter sub–assy
Resistance at –20C(–4F)
at 20C(68F)
at 60C(140F)
13.6 – 18.4 kΩ
2.21 – 2.69 kΩ
0.493 – 0.667 kΩ
Camshaft timing oil control valve assy
Resistance at 20 C (68 F) 6.9 – 7.9 Ω
Accelerator pedal assy
Resistance 2 (VPA2) – 3 (EP1)
5 (VPA1) – 1 (EP2)
6 (VCP1) – 3 (EP1)
4 (VCP2) – 1 (EP2)
5.0 kΩ or less
5.0 kΩ or less
2.25 – 4.75 kΩ
2.25 – 4.75 kΩ
Throttle body assy
3 (VC) – 6 (GND)
2 (M+) – 1 (M–)
1.2 – 3.2 kΩ at 20 C (68 F)
0.3 – 100 kΩ at 20 C (68 F)
E.F.I. Engine coolant temperature sensor
Resistance Approx. 20C (68F)
Approx. 80C (176F)
2.29 – 2.6 kΩ
0.300 – 0.327 kΩ
E.F.I. Circuit opening relay assy
Specified condition 1 – 2
3 – 5
Continuity
No continuity
1MZ–FE
Throttle body
Standard throttle valve opening percentage 60 % or more
Accelerator pedal position sensor
Standard voltage 0.6 – 1.0 V
Intake air flow meter assy
Resistance at –20C(–4F)
at 20C(68F)
at 60C(140F)
13.6 – 18.4 kΩ
2.21 – 2.69 kΩ
0.493 – 0.667 kΩ
Accelerator pedal assy
Resistance 2 (VPA2) – 3 (EP1)
5 (VPA1) – 1 (EP2)
6 (VCP1) – 3 (EP1)
4 (VCP2) – 1 (EP2)
5.0 kΩ or less
5.0 kΩ or less
2.25 – 4.75 kΩ
2.25 – 4.75 kΩ
Throttle body assy
M+ – M– 0.3 – 100 kΩ at 20 C (68 F)
Throttle position sensor
Resistance VC – E2 1.2 – 3.2 kΩ
Coolant temperature sensor
Resistance Approx. 20C (68F)
Approx. 80C (176F)
2.32 – 2.59 kΩ
0.310 – 0.326 kΩ
