A62390
FP
+B
–FUEL FUEL SYSTEM (2AZ–FE)
11–7
1451Author: Date:
2002 CAMRY REPAIR MANUAL (RM881U)
(b) When not using hand–held tester
(1) Remove the circuit opening relay.
(2) Using a service wire connect terminals FP and +B
of the relay block.
NOTICE:
Pay due attention to the terminal connecting position to
avoid a malfunction.
(3) Turn the ignition switch ON, and check that the fuel
pump operates.
NOTICE:
Do not start the engine.
(c) Check that there are no fuel leaks after doing mainte-
nance anywhere on the fuel system.
To Next Page
