F41010
F41687
F41000
F41688
–PARKING BRAKE PARKING BRAKE CABLE ASSY NO.1
33–13
2064Author: Date:
(c) Remove the lock nut, adjusting nut, clip and disconnect
the parking brake cable assy No.1 from the parking brake
control pedal assy.
(d) Remove the 2 nuts, 2 bolts, clip and parking brake cable
assy No.1.
17. REMOVE PARKING BRAKE CABLE ASSY
NO.1(LEVER TYPE PARKING BRAKE)
(a) Remove the lock nut and adjusting nut from the parking
brake cable assy No.1.
(b) Remove the 2 bolts and console box mounting bracket
No.2.
(c) Remove the 2 bolts and separate the parking brake cable
No.1 from the parking brake equalizer.
To Next Page
