Toyota 2002 Camry User Manual

C90579
C90580
C90580
C90579
D25415
40–54
–AUTOMATIC TRANSMISSION / TRANS FLOOR SHIFT CABLE TRANSMISSION CONTROL
SHIFT
2129Author: Date:
2002 CAMRY REPAIR MANUAL (RM881U)
(d) Disconnect the control cable from the control cable
clamp.
(e) Disconnect the floor shift cable from the transmission
floor shift assy.
(f) Pull out the control cable from the body.
(g) Remove the shift cable grommet retainer No. 2.
10. INSTALL FLOOR SHIFT CABLE TRANSMISSION
CONTROL SHIFT
(a) Put in the control cable to the body.
(b) Install the shift cable grommet retainer No.2 to the floor
shift cable.
(c) Install the floor shift cable as shown in the illustration.
HINT:
 Install it with the uneven surface facing to up.
 Fit the claws securely.
(d) Connect the control cable to the control cable clamp.
(e) Install the control cable and a new clip to the bracket.
