02–34
–
PREP
ARA
TION
BRAKE
77
Author:
Date:
2002 CAMRY REP
AIR MANUAL (RM881U)
09905–00013
Snap Ring Pliers
BRAKE MASTER
CYLINDER
SUB–ASSY
Equipment
V
ernier
calipers
Dial indicator
T
orque wrench
Brake drum gauge
Lubricant
Item
Capacity
Classification
Brake fluid
–
SAE J1703 or FMVSS No. 1
16 DOT3
76
78
