9.3 Check alternator -C-
– Connect Vehicle Diagnosis, Testing and Information System
-VAS 5051A- ⇒ page 281 .
Select “guided fault finding” in Vehicle Diagnosis, Testing and In‐
formation System -VAS 5051A- .
– Using the “Go to” key, select “Function/component selection”
and the following menu items one after the other:
♦ Body
♦ Electrical System
♦ 27 - Starter, current supply
♦ Electrical components
♦ C - Alternator
9.4 Alternator, 1.6 l injection engine
9.4.1 Assembly overview
1 - Hexagon head collared bolt
❑ M8x108
❑ 23 Nm
2 - Hexagon head collared
bolts
❑ M8x50
❑ 23 Nm
3 - Bracket
4 - Hexagon head collared nut
❑ M8
5 - Hexagon head collared
bolts
❑ M8x45
❑ 52 Nm
6 - Protective cap
7 - Hexagon head collared nut
❑ M8
8 - Cross-head screw
❑ M5x21
❑ 4.5 Nm
9 - Hexagon nut, flat
❑ M8
10 - Plain washer
❑ M5
11 - Phillips screws
❑ M4x19
❑ 2 Nm
12 - Cross-head screw
❑ M4x13
Jetta 2005 ➤ , Bora 2006 ➤
Electrical System - Edition 05.2005
9. Alternator 99
