⇒ Current flow diagrams, Electrical fault finding and Fitting loca‐
tions
The central locking and anti-theft alarm system aerial -R47- is laid
from the central locking and anti-theft alarm system aerial -J393-
to the A-pillar (driver side) in the main wiring loom.
Note
♦ The antenna cannot be repaired as this would adversely affect
the reception quality.
♦ In the event of damage, it is necessary to replace the central
locking and anti-theft alarm system aerial -R47- .
10.5 Alarm horn -H12-
The alarm horn -H12- is located on the right of the A-pillar in the
wing.
10.5.1 Removing and installing the alarm horn
-H12-
Special tools and workshop equipment required
♦ Drill -VAS 5134-
♦ Twist drill ∅ 6 mm
♦ Pop rivet pliers -VAS 5072-
Note
The anti-theft alarm system must be deactivated before the alarm
horn is removed ⇒ page 277 .
Removing:
– Switch off ignition and all electrical consumers and pull out
ignition key.
Jetta 2005 ➤ , Bora 2006 ➤
Electrical System - Edition 05.2005
10. Anti-theft alarm system (ATAS) 279
