♦ Vehicle Diagnosis, Testing and Information System -VAS
5051A-
♦ Diagnosis lead -VAS 5051/6A- (5 m)
♦ Diagnosis lead -VAS 5051/5A- (3 m)
Note
Only these leads are to be used for diagnosis, as they are the only
ones fitted with CAN lines and therefore allowing CAN diagnosis
and/or CAN communication.
Connecting Vehicle Diagnosis, Testing and Information System -
VAS 5051A- :
– Apply handbrake.
– On vehicles with automatic gearbox, move selector lever to
position “P” or “N”.
– On vehicles with manual gearbox, move gear stick to neutral
position.
– With the ignition switched off, connect vehicle diagnosis, test‐
ing and information system -VAS 5051A- using diagnostic lead
-VAS 5051/6A- to diagnostic interface -arrow- in vehicle.
– Switch ignition on.
– Switch off all electrical consumers.
Note
Any additional vehicle diagnosis, measuring and information sys‐
tems and/or vehicle diagnosis and service information systems
are connected in the sequence described above.
Jetta 2005 ➤ , Bora 2006 ➤
Electrical System - Edition 05.2005
282 Rep. Gr.97 - Wiring
