ROTARY INDEXING TABLE CONTROLLER
EF2...B
OPERATION / DESCRIPTION OF WEISS SOFTWARE | 8.5 Operation and Monitoring
8.5.1.3 Forcing via the "Open separate user screen" button:
Fig. 68: Forcing via the "Open separate user screen" button
With a separate user screen or second browser window open, forcing can only be carried out by
the browser window from which the operating option has been requested.
1. Open a separate user screen.
 Opening a separate user screen can make it unnecessary to open a second browser window.
 Opening this window gives the user an operating option.
 The window underneath it is now only used for monitoring.
 The signals from a higher-level controller can be overwritten or forced - if there is no controller.
2. Activate forcing for an input or output.
3. Set the force value for the activated input or output.
 The green light indicates that the process state is active.
4. Close the separate user screen.
 The operating option is ended by closing the window.
4.
1.
2.
3.
