Manual R06-2016 33 / 172
ROTARY INDEXING TABLE CONTROLLER
EF2...B
COMPONENT DESCRIPTIONS | 3.7 SIMOTION D410-2 Control Unit
3.7.2 MAC Addresses
A second type plate for the MAC address of the Ethernet interface and the PROFINET interface is attached to the
front of the device.
3.7.3 CompactFlash Card
The CompactFlash card is mandatory for operation of the SIMOTION D410-2.
The SIMOTION Kernel (SIMOTION D410-2 firmware) and the software used to control the drives (WEISS firmware)
are stored on the CompactFlash card.
(1) Data matrix code
(2) Module designation
(3) Order number
(4) Ethernet interface
MAC address of X127
(5) PROFINET IO interface
MAC address of X150
(6) Serial number
(7) HW version
