Manual R06-201632 / 172
ROTARY INDEXING TABLE CONTROLLER EF2...B
COMPONENT DESCRIPTIONS | 3.7 SIMOTION D410-2 Control Unit
3.7.1 Technical data
Refer to the device manual of the manufacturer for further information.
Pos. Description
[A] LED status indicators
[B] CF card slot
[C] Type plate
Pos. Interface Description
(1) PM-IF Interface to the power module (on the rear)
(2) X23 Encoder interface
(3) X100 DRIVE-CLIQ interface
(4) X150 PROFINET IO interfaces
(5) X21 PROFIBUS DP interface
(6) X124 Electronics power supply
(7) X120
Temperature sensor connection
Fail-safe digital inputs
EP terminals
(8) X121
Isolated digital inputs
High-speed digital inputs / outputs
(9) X130
Isolated digital input
Fail-safe digital output
(10) X131
High-speed digital inputs / outputs
Analog input
(11) X127 Service interface
System data, dimensions, weight
Dimensions W x H x D 73 x 190.7 x 74.4 mm
Permissible temperature range
Storage
Operation
-25 °C....+55 °C
0 °C....+55 °C
Protection class IP 20 (EN 60529)
Protection class
Class I (with protective conductor connection) and class III (PELV) acc. to
EN 61800-5-1:2007
Maximum weight
0.8 kg (without packaging)
1.0 kg (with packaging)
Electrical connection values
Power supply 24 V DC (permissible range: 20.4 ... 28.8 V)
Ripple Max. 5% at 24 VDC
Non-periodic overvoltage
Max. 35 VDC
(Condition: Max. 500 ms, 50 s recovery time, max. 10 results/h)
Current consumption, typical
1)
< 0.8 A
Starting current, typical
1)
3.0 A
Power loss, typical
1)
< 20 W
1)
With no load on inputs/outputs and no 24 V supply via DRIVE-CLiQ or PROFIBUS interface
