ROTARY INDEXING TABLE CONTROLLER
EF2...B
APPENDIX | 13.2 EF2...B; 1.5 kW to 3.0 kW Controllers connection examples
13.2.6 SIL3 Safety relais connection example
Page Page
examples indexer control
Ed.
02
Original
---
---
djahn +
Date
Date
Replaced by
EF2_3ph_1,5-(3)kW Sil3
wiring example SIL3 safety relais 1,5-(3)kW
1
Modification
0 76
Appr
Replacement of
8 93
14
04
4
13.06.2016
WEISS GmbH
03
2
=
Name
5
Siemensstraße 17 D-74722 Buchen Tel. +49 (0)6281-5208-0
The customer, is responsible for the assessment of risk and for the choice of the switching devices
Logic
1 | Autostart / Monitored Start 2 | Cross fault detection OFF / ON 3 | 2 single-ch. sensors / 1 double-ch. sensor 4 | Startup Test yes / no
SYS
SET / RESET
T1 IN2PAR T2 INF INS
-KF2
SIEMENS
3SK1122-1CB41
IN1
Q1 Q2 Qt2Qt1
+ A1
-
A2
INK
emergency stop start
channel 1 channel 2
Q1/Q2 undelayed Qt1/Qt2 delayed delay time according start-up EF2
A1 A2
-QA2
Motor contactor
3RT2017-1BB42
1 2 /01.2 3 4 /01.2 5 6 /01.2
21 22 /03.4
21
22
-QA2
/03.3
11 12
-SF1
21 122
13 14
-SF2
+24VDC
/02.9
GND
/02.9
quick-stop DI 9
/02.7
STO_DI16
/02.7
STO_DI17
/02.7
monitoring motor contactor DI 3
/02.7
+24VDC
/ 04.0
GND
/ 04.0
