1128500 WPC 2000 User Manual
3-54 Initialization, Setup, and Checkout
Foot Switch Test
This test, which should be run only if you have an optional Foot Switch, verifies that your
Foot Switch is operating properly. To perform the test, do the following, referring to
Figure 3-14, Figure 3-15, or Figure 3-16 for LED locations:
1. Set the Stroke Select switch to “SINGLE” and the Mode Select switch to “FOOT.” Verify
that the “Single stroke select” and “Foot control select” LEDs on the WPC 2000 Display
board are lit.
2. Make sure that option switch 3 on the WPC 2000 Main Processor board is set to OFF, its
default setting (see Enabling Foot Control in a Foot Switch, page 3-27).
3. Power down, then power back up the WPC 2000, if necessary, to enable the settings
change. The WPC 2000 is now in Foot Trip mode, the press stroking each time the Foot
Switch is depressed.
INJURY DURING TESTING
• Keep all personnel away from the press during testing.
• Be sure there is no die or other tooling in the press during testing.
Failure to comply with these instructions will result in death or serious injury.
MISSING SAFEGUARDS
Install a light curtain for use with the Foot Switch option. A light curtain is required for using the
Foot Switch.
Failure to comply with these instructions will result in death or serious injury.
These instructions refer to the Auto Carry-up Angle, which is factory set to one of the following
values:
• 170° if the press does not have a light curtain
• 149° if the press does have a light curtain
Refer to Setting the Auto Carry-up Angle, page 3-13 for information about the Auto Carry-up
feature.
Depress the Foot Switch quickly and fully to initiate a stroke. If you depress the Foot
Switch slowly or partially, the press will not stroke.
