C-6 Option 1 User Inputs
Table C-2. WPC 2000 Option 1 Board: Wiring Connections, TB601
Pin # User Input
Terminal for Jumper
Bypass Connection
Upper Row
431 User input 32 + (cross-checked with user input 33) +24 Vdc
432 User input 34 + (cross-checked with user input 35) +24 Vdc
433 User input 12 - Ground
434 User input 13 - Ground
435 User input 14 - Ground
436 User input 15 - Ground
437 +24 Vdc
Lower Row
448 User input 22 + +24 Vdc
449 User input 23 + +24 Vdc
450 User input 24 + +24 Vdc
451 User input 25 + +24 Vdc
452 User input 36 + (cross-checked with user input 37) +24 Vdc
453 User input 38 + (cross-checked with user input 39) +24 Vdc
454 Ground
Table C-3. WPC 2000 Option 1 Board: Wiring Connections, TB602
Pin # User Input
Terminal for Jumper
Bypass Connection
Upper Row
438 User input 33 + (cross-checked with user input 32) +24 Vdc
439 User input 35 + (cross-checked with user input 34) +24 Vdc
440 User input 16 - Ground
441 User input 17 - Ground
442 User input 18 - Ground
443 User input 19 - Ground
444 User input 20 - Ground
445 User input 21 - Ground
446 +24 Vdc
447 +24 Vdc
Lower Row
455 User input 26 + +24 Vdc
456 User input 27 + +24 Vdc
457 User input 28 + +24 Vdc
458 User input 29 + +24 Vdc
459 User input 30 + +24 Vdc
