1128500 WPC 2000 User Manual
C-8 Option 1 User Inputs
Troubleshooting
Table C-4 shows the fault code associated with each Option 1 user input that appears on your
WPC 2000 display when there is a problem with the auxiliary equipment that input is
connected to.
To correct the problem that caused the fault code to display, check the equipment and wiring
connected to that user input. When you have corrected the problem, reset WPC 2000. If the
problem recurs, contact Wintriss Tech. Support.
Table C-4. WPC 2000 Option 1 Fault Codes
Fault Code User Input Stop Type Pin #
Terminal for
Jumper Connection
120 User 12 Top-stop 433 Ground
121 User 13 Top-stop 434 Ground
122 User 14 Top-stop 435 Ground
123 User 15 Top-stop 436 Ground
124 User 16 Top-stop 440 Ground
125 User 17 E-stop 441 Ground
126 User 18 E-stop 442 Ground
127 User 19 E-stop 443 Ground
128 User 20 E-stop 444 Ground
129 User 21 E-stop/Lockout 445 Ground
130 User 22 Top-stop 448 +24 Vdc
131 User 23 Top-stop 449 +24 Vdc
132 User 24 Top-stop 450 +24 Vdc
133 User 25 Top-stop 451 +24 Vdc
134 User 26 Top-stop 455 +24 Vdc
135 User 27 E-stop 456 +24 Vdc
136 User 28 E-stop 457 +24 Vdc
137 User 29 E-stop 458 +24 Vdc
138 User 30 E-stop/Lockout 459 +24 Vdc
139 User 31 E-stop 460 +24 Vdc
140, 144
User 32 paired
with User 33
E-stop 431 +24 Vdc
E-stop 438 +24 Vdc
141, 145
User 34 paired
with User 35
E-stop 432 +24 Vdc
E-stop 439 +24 Vdc
142, 146
User 36 paired
with User 37
E-stop/Lockout 452 +24 Vdc
E-stop/Lockout 461 +24 Vdc
143, 147
User 38 paired
with User 39
E-stop/Lockout 453 +24 Vdc
E-stop/Lockout 462 +24 Vdc
