Initialization, Setup, and Checkout 3-1
Chapter 3. Initialization, Setup, and
Checkout
This chapter shows you how to initialize and set up your WPC 2000 and perform final
checkout tests.
Viewing and Setting Press Parameters
The WPC 2000 allows you to view and, in some cases, to set the following press parameters:
• Crankshaft angle or strokes per minute (SPM)
• 90° stop time test result
• Counter
• Stopping time
• Counter preset
• Stopping angle
• Top-stop angle
• Stop-time limit
• Auto carry-up angle
• Micro-inch time setting
OPERATOR STATION WIRED INCORRECTLY
Run all necessary tests to verify that each Operator Station is wired correctly and provides proper
anti-tie-down and anti-repeat protection.
Failure to comply with these instructions will result in death or serious injury.
MORE OPERATORS THAN OPERATOR STATIONS
• Ensure that there are the same number of active operator stations as there are operators if the
press is not equipped with properly installed and operating light curtains.
• During setup, lockout/tagout the press if there are more operators than operator stations.
• Verify at every shift change that there are the same number of active operator stations as there
are operators if the press is not equipped with properly installed and operating light curtains.
Failure to comply with these instructions will result in death or serious injury.
TWO-HAND CONTROL TOO CLOSE TO HAZARDOUS AREA
Verify at each shift change that any moveable Two-hand controls are located at least the safety
distance from the pinch point or hazardous area.
Failure to comply with these instructions will result in death or serious injury.
