WPC 2000 User Manual 1128500
Operation 4-19
Operating the Press in Automatic Continuous
On-demand Mode
For information on using Automatic Continuous On-demand mode, call Wintriss Tech.
Support.
Operating the Press in Bar Mode
To operate the press in Bar mode, you must have the Bar Mode Control option. To activate
Bar mode and bar the press, do the following:
1. Turn the Stroke Select switch to “INCH.”
2. Turn the Mode Select switch to “2 HAND.”
3. Turn off the press motor.
4. On the Bar Control enclosure (see Figure 2-26, page 2-47), turn the Select switch to
“ON.”
5. When the flywheel stops turning, press the Operate button on the Bar Control enclosure.
IMPROPER SAFEGUARDING
Ensure that the machine guarding system is installed and maintained according to OSHA standard
1910.217, ANSI B11.1, ANSI B11.19 and any other regulations and standards that apply. Ensure
that guarding is properly installed to prevent access to the machine over, under or around any
guarding device.
Failure to comply with these instructions will result in death or serious injury.
PRESS STARTING UNEXPECTEDLY
• Ensure that light curtains and other safeguards are properly installed and operating to protect
operators when using Automatic Continuous On-demand mode, in which a stroke can occur
unexpectedly.
• Ensure that guarding is properly installed to prevent access to the machine over, under or
around any guarding device.
Failure to comply with these instructions will result in death or serious injury.
INJURY WHEN USING BAR MODE
• Keep all personnel away from the press while it is being barred
• Use a spring-loaded turnover bar when you bar the press.
Failure to comply with these instructions will result in death or serious injury.
