1128500 WPC 2000 User Manual
4-20 Operation
6. Bar the press using a spring-loaded bar.
7. If an F26 error appears in the display, press the Reset/Select button to clear it, and
continue with the barring operation.
Multiple Operator Stations
If you have wired two Operator Stations to your WPC 2000 (see Installing Multiple Operator
Stations, page 2-17) and option switch 6 on S102 is set to OFF (see page 3-33), the Run/Inch
palm switches on each Operator Station must be pressed within a 1/2-second “palm time”
(“synchronous time” in ANSI terminology) window, and both pairs of palm switches must be
pressed within a 5-second “concurrent time” window.
If you have installed more than two Operator Stations, you must set option switch 6 on S102
to ON to establish a 5-second concurrent time for all Op. Stations. In addition, all Operator
Stations except the Op. Station connected to the “A” inputs must contains a Two-hand Control
module to provide the required 1/2-second palm time (“synchronous” time in ANSI
terminology).
If you have dual Operator Stations, make sure to set the Operator Station Select Switch on the
front panel of your WPC 2000 to enable either the first station, the second station, or both
stations.
When barring the press, do not rotate the flywheel too quickly. If the crankshaft moves
faster than 6 SPM, WPC 2000 will stop the ram and fault code F26 will appear in the LED
display. Press the Reset/Select button to continue barring the press.
HAZARDS EXPOSED BY NON-WORKING OPERATOR STATION
• Safeguard the point of operation exposed by the non-working Operator Station when using
multiple operator stations. The exposed area near a disabled Operator Station must be properly
guarded.
• Ensure that guarding is properly installed to prevent access to the machine over, under or
around any guarding device.
Failure to comply with these instructions will result in death or serious injury.
Do not attempt to install more than two Operator Stations until you have contacted Wintriss Tech.
Support. All Operator Stations in a mutli-Op.-Station configuration except the Op. Station wired to
the “A” inputs must contain a Two-hand Control module.
