WPC 2000 User Manual 1128500
Installation 2-19
WPC 2000 provides wiring connections for up to two pairs of light curtains (see Table 2-17,
page 2-62). If you wire two sets of light curtains, you must enable them on S101 option
switch 6 (see Table 3-9, page 3-29).
Installing Shadow Light Curtains
Wiring connections for Shadow light curtains are provided in the following wiring diagrams
at the back of the manual:
• Shadow V–Figure 3
• Shadow VI–Figure 10
• Shadow VI Integrated–Figure 11
• Shadow VII–Figures 15 and 16
• Shadow 8–Figures 18 and 19
For Shadow I or Shadow II wiring, contact Wintriss Tech. Support. For complete Shadow
light curtain mounting instructions, see your Shadow user manual.
Setting Jumpers for Shadow VII and Shadow 8 Light Curtains
When you install Shadow VII or Shadow 8 light curtains on your press, you must set jumpers
JP121-JP124 on the WPC 2000 Main Processor board (see Figure 2-12, page 2-23 or
Figure 2-13, page 2-24) to the positions shown in Table 2-1. Wiring diagrams are provided in
figures 15 (Shadow VII control box), 16 (Shadow VII DIN controller), 18 (Shadow 8 optional
control), and 19 (Shadow 8 wired directly to WPC 2000) at the back of the manual.
Installing Non-Shadow Light Curtains
Table 2-1. Shadow VII and Shadow 8 Light Curtain Jumper Settings
Jumper on Main
Processor Board Settings
Light Curtain #1
JP123 PNP
JP124 INT
Light Curtain #2
JP121 PNP
JP122 INT
It is your responsibility to ensure that your light curtains are control reliable and intended for use on
a mechanical power press as a primary point-of-operation guard. The manufacturer of your light
curtain should be able to provide the necessary information.
Failure to comply with these instructions could result in death or serious injury.
