WPC 2000 User Manual 1128500
Operation 4-11
Operating the Press in Single-stroke Mode
To operate the press in Single-stroke mode, do the following:
1. Turn the Stroke Select switch to “SINGLE.”
2. Turn the Mode Select switch to “2 HAND” for operation in Two-hand mode, to
“1 HAND” for operation in One-hand or One-hand Control mode, or to “FOOT” for
operation in Foot mode. Instructions for operating the press in each mode are provided
below.
Single-stroke, Two-hand Operation
IMPROPER SAFEGUARDING
Ensure that the machine guarding system is installed and maintained according to OSHA
regulation 1910.217, ANSI standards B11.1 and B11.19, and any other regulations or standards
that apply. Ensure that guarding is properly installed to prevent access to the machine over, under
or around any guarding device.
Failure to comply with these instructions will result in death or serious injury.
If you are running Two-hand Only firmware, One-hand and Foot modes are not available.
OPERATOR STATION WIRED INCORRECTLY
Run all necessary tests to verify that each Operator Station is wired correctly and provides proper
anti-tie-down (see page 3-48) and anti-repeat (see page 3-49) protection.
Failure to comply with these instructions will result in death or serious injury.
MORE OPERATORS THAN OPERATOR STATIONS
• Ensure that there are the same number of active operator stations as there are operators if the
press is not equipped with properly installed and operating light curtains.
• During setup, lockout/tagout the press if there are more operators than operator stations.
• Verify at every shift change that there are the same number of active operator stations as there
are operators if the press is not equipped with properly installed and operating light curtains.
Failure to comply with these instructions will result in death or serious injury.
