Troubleshooting 5-13
For F48 errors, check to see whether the air pressure is turned off or set too low,
and correct if necessary.
Customized Status Codes
Problem: A failure has occurred in an auxiliary press function (e.g., lubrication system)
wired to a WPC 2000 user input. Refer to Table 5-2, page 5-13 for specific faults.
See also the separate remedies for faults F17, F18, F50, and F58, which apply to
the cross-checked input pairs 8/9 and 10/11.
Remedy: Diagnose and correct the condition that the input is monitoring. If the error
persists after you reset the unit, contact Wintriss Tech. Support.
Problem: A failure has occurred in an auxiliary press function wired to WPC 2000
cross-checked input pair 10 and 11 (see Table 5-2). One or both inputs are open.
Remedy: Diagnose and correct the condition that the inputs are monitoring. If the error
persists after you reset the unit, contact Wintriss Tech. Support.
F50 through F58
Table 5-2. Fault Codes for User Inputs
Fault
Code
User Input
(Interlock) Stop Type
Pin
#
Jumper
Connection
(Bypass)
51 User 1 ESTOP 21 +24 Vdc
52 User 2 ESTOP 82 +24 Vdc
53 User 3 TOP STOP 71 +24 Vdc
54 User 4 ESTOP 83 Ground
55 User 5 TOP STOP 72 Ground
56 User 6 TOP STOP 84 Ground
57 User 7 ESTOP/
LOCKOUT
73 Ground
58, 17
User 8 paired
with 9
ESTOP
85 Ground
User 9 paired
with 8
74 Ground
50, 18
User 10 paired
with 11
ESTOP/
LOCKOUT
86 Ground
User 11 paired
with 10
18 Ground
F50
