Zebra DS8178 Product Reference Guide

User Preferences 5 - 7
Direct Decode Indicator
Parameter # 859 (SSI # F2h 5Bh)
This feature is only supported in Auto Aim and Standard (Level) trigger modes. Scan a bar code below to select
optional blinking of the illumination on a successful decode
• Disable Direct Decode Indicator - illumination does not blink on a successful decode.
• 1 Blink - illumination blinks once upon a successful decode.
• 2 Blinks - illumination blinks twice upon a successful decode.
*Disable Direct Decode Indicator
(0)
1 Blink
(1)
2 Blinks
(2)

Zebra DS8178 Specifications

General

Product color	Black
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Photo diode
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Optical sensor resolution	1280 pixels
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
PC connection	RS-232/USB
Wireless range	100 m
Bluetooth version	4.0
Standard interfaces	USB, RS-232, Bluetooth
Connectivity technology	Wired & Wireless
Battery life	83 h
Battery capacity	2500 mAh
Power source type	Battery

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	235.3 g
