Zebra DS8178 Product Reference Guide

Data Capture 2 - 9
Decode Ranges
Table 2-4 DS8178 Decode Ranges
Bar Code
Type
Symbol Density
DS8178-SR
Typical Working Ranges
DS8178-HC
Typical Working Ranges
Near Far Near Far
Code 39 3.0 mil 2.2 in/5.6 cm 5.0 in/12.7 cm 1.4 in/3.6 cm 5.1 in/13.0 cm
20.0 mil 0.0 in/0.0 cm 36.8 in/93.5 cm 0.0 in/0.0 cm 22.4 in/56.9 cm
Code 128 3.0 mil 2.6 in/6.6 cm 4.5 in/11.4 cm 1.8 in/4.6 cm 4.1 in/10.4 cm
5.0 mil 1.6 in/4.1 cm 8.4 in/21.3 cm 1.2 in/3.0 cm 8.1 in/20.6 cm
15 mil 0.0 in/0.0 cm 27.1 in/68.8 cm 1.0 in/ 2.5 cm 16.9 in/42.9 cm
100% UPC 13.0 mil 0.0 in/0.0 cm 24.0 in/61.0 cm 0.0 in/0.0 cm 15.9 in/40.4 cm
PDF 417 5 mil 2.3 in/5.8 cm 6.4 in/16.3 cm 1.5 in/3.8 cm 6.1 in/15.5 cm
6.67 mil 1.8 in/4.6 cm 8.5 in/21.6 cm 1.1 in/2.8 cm 8.1 in/20.6 cm
Data Matrix 5.0 mil n/a n/a 1.9 in/4.8 cm 4.5 in/11.4 cm
7.5 mil 2.1 in/5.3 cm 6.9 in/ 17.5 cm 1.3 in/ 3.3 cm 6.7 in/17.0 cm
10.0 mil 1.1 in/2.8 cm 9.9 in/ 25.1 cm 0.6 in/1.5 cm 8.5 in/ 21.6 cm
QR Code 10.0 mil 1.0 in/2.5 cm 8.6 in/ 21.8 cm 0.6 in/1.5 cm 7.7 in/19.6 cm
20.0 mil 0.1 in/0.3 cm 17.6 in/ 44.7 cm 0.0 in/0.0 cm 12.5 in/ 31.8 cm

Zebra DS8178 Specifications

General

Product color	Black
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Photo diode
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Optical sensor resolution	1280 pixels
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
PC connection	RS-232/USB
Wireless range	100 m
Bluetooth version	4.0
Standard interfaces	USB, RS-232, Bluetooth
Connectivity technology	Wired & Wireless
Battery life	83 h
Battery capacity	2500 mAh
Power source type	Battery

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	235.3 g
