Zebra DS8178 Product Reference Guide

User Preferences 5 - 29
Triggered Timeout, Same Symbol
Parameter # 724 (SSI # F1 D4)
Scan Enable Triggered Timeout, Same Symbol below to apply Timeout Between Decodes, Same Symbol
(parameter #137 on page 5-28) in hand-held trigger mode. Subsequent scans of Enable Triggered Timeout,
Same Symbol are ignored until Timeout Between Decodes, Same Symbol expires.
NOTES 1. This feature does not apply to Timeout Between Decodes, Different Symbols.
2. Timeout Between Decodes, Same Symbol should not be greater than or equal to the Time Delay
to Low Power Mode (parameter #146 on page
5-17).
Enable Triggered Timeout, Same Symbol
* Disable Triggered Timeout, Same Symbol

Zebra DS8178 Specifications

General

Product color	Black
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Photo diode
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Optical sensor resolution	1280 pixels
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
PC connection	RS-232/USB
Wireless range	100 m
Bluetooth version	4.0
Standard interfaces	USB, RS-232, Bluetooth
Connectivity technology	Wired & Wireless
Battery life	83 h
Battery capacity	2500 mAh
Power source type	Battery

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	235.3 g
