Zebra DS8178 Product Reference Guide

Keyboard Wedge Interface 11 - 3
Keyboard Wedge Parameter Defaults
Table 11-1 lists the defaults for Keyboard Wedge host parameters. To change any option, scan the appropriate bar
code(s) in Keyboard Wedge Host Parameters on page 11-4.
NOTE See Appendix B, Country Codes for Keyboard Wedge Country Keyboard Types (Country Codes).
See Appendix A, Standard Parameter Defaults for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
Table 11-1 Keyboard Wedge Host Default Table
Parameter Default
Page
Number
Keyboard Wedge Host Parameters
Keyboard Wedge Host Type IBM AT Notebook 11-4
Ignore Unknown Characters Transmit 11-4
Keystroke Delay No Delay 11-5
Intra-Keystroke Delay Disable 11-5
Alternate Numeric Keypad
Emulation
Enable 11-6
Quick Keypad Emulation Enable 11-6
Simulated Caps Lock Disable 11-7
Caps Lock Override Disable 11-7
Convert Wedge Case No Convert 11-8
Function Key Mapping Disable 11-8
FN1 Substitution Disable 11-9
Send Make and Break Send Make and Break Scan Codes 11-9

Zebra DS8178 Specifications

General

Product color	Black
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Photo diode
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Optical sensor resolution	1280 pixels
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
PC connection	RS-232/USB
Wireless range	100 m
Bluetooth version	4.0
Standard interfaces	USB, RS-232, Bluetooth
Connectivity technology	Wired & Wireless
Battery life	83 h
Battery capacity	2500 mAh
Power source type	Battery

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	235.3 g
