13 - 4 DS8178 Digital Scanner Product Reference Guide
Parameters
This section describes the parameters controlling the IDC firmware and provides programming bar codes for
setting them.
To set parameters requiring a range of values, scan the parameter bar code followed by two, three, or four bar
codes from Appendix G, Numeric Bar Codes corresponding to the desired value. Scan two numeric bar codes for
parameters with a maximum value of less than 100, for example, IDC Minimum Text Length. IDC Delay Time
requires scanning three digits since the maximum value is 200. Leading zeros are required.
Alternatively, use the sample application to set parameters using the parameter name. The application provides
prompts and error checking to assist in setting the parameters correctly and easily. You must use an application to
set a parameter to a negative value, as the IDC X Coordinate can require.
Table 13-1 Intelligent Document Capture (IDC) Parameter Defaults
Parameter Parameter Name
Parameter
Number
SSI Number Default
Page
Number
Intelligent Document Capture (IDC)
IDC Operating Mode
DocCap_MODE 594 F1h 52h Off 13-5
IDC Symbology DocCap_SYMBOLOGY 655 F1h 8Fh 001 13-6
IDC X Coordinate DocCap_X 596 F4h F1h 54h -151 13-7
IDC Y Coordinate DocCap_Y 597 F4h F1h 55h -050 13-7
IDC Width DocCap_WIDTH 598 F1h 56h 0300 13-8
IDC Height DocCap_HEIGHT 599 F1h 57h 0050 13-8
IDC Aspect DocCap_ASPECT 595 F1h 53h 000 13-9
IDC File Format Selector DocCap_FMT 601 F1h 59h JPEG 13-9
IDC Bits Per Pixel DocCap_BPP 602 F1h 5Ah 8 BPP 13-10
IDC JPEG Quality DocCap_JPEG_Qual 603 F1h 5Bh 065 13-10
IDC Find Box Outline Sig_FINDBOX 727 F1h D7h Disable 13-11
IDC Minimum Text Length DocCap_MIN_TEXT 656 F1h 90h 00 13-11
IDC Maximum Text Length DocCap_MAX_TEXT 657 F1h 91h 00 13-12
IDC Captured Image
Brighten
Sig_BRIGHTEN 654 F1h 8Eh Enable 13-12
IDC Captured Image
Sharpen
Sig_SHARPEN 658 F1h 92h Enable 13-13
IDC Border Type DocCap_BORDER 829 F2h 3Dh None 13-14
IDC Delay Time DocCap_DELAY 830 F2h 3Eh 000 13-15
IDC Zoom Limit Sig_MIN_PERCENT 651 F1h 8Bh 000 13-15
IDC Maximum Rotation Sig_MAX_ROT 652 F1h 8Ch 00 13-16

Zebra DS8178 Specifications

General

Product color	Black
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Photo diode
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Optical sensor resolution	1280 pixels
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
PC connection	RS-232/USB
Wireless range	100 m
Bluetooth version	4.0
Standard interfaces	USB, RS-232, Bluetooth
Connectivity technology	Wired & Wireless
Battery life	83 h
Battery capacity	2500 mAh
Power source type	Battery

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	235.3 g
