Technical Specifications
NOTE Operating current specifications are subject to change.
Table 3-2 Technical Specifications
Item Description
Physical Characteristics
Dimensions
Scanner
Presentation Cradle
Desk/Wall Cradle
6.6 in H x 2.6 in W x 4.2 in D / 16.8 cm H x 6.7 cm W x 10.6 cm D
2.9 in H x 3.7 in W x 4.8 in D / 7.3 cm H x 9.4 cm W x 12.3 cm D
2.8 in H x 3.3 in W x 8.3 in D / 7.2 cm H x 8.4 cm W x 21.1 cm D
Weight - DS8178-SR/DL
Scanner
Presentation Cradle
Desk/Wall Cradle
8.2 oz / 232 g
5.4 oz / 153 g
6.5 oz / 183 g
Weight - DS8178-HC
Scanner
Presentation Cradle
Desk/Wall Cradle
8.3 oz / 237 g
6.5 oz / 183 g
7.1 oz / 202 g
Cradle Operating Currents
CR8178-SC Operating Current (mA)
T
A
=25C
Mode Typ Max
Idle @ VIN = 12V 43 50
Idle @ VIN = 5V 93 100
Charging, Standard USB 470 500
Charging, BC1.2 CDP 1350 1500
Charging, BC1.2 DCP 1100 1200
Charging, 5V non-USB 730 750
Charging, 12V non-USB 743 1000
CR8178-PC Operating Current (mA)
T
A
=25C
Mode Typ Max
Idle @ VIN = 12V 37 45
Idle @ VIN = 5V 77 85
Charging, Standard USB 470 500
Charging, BC1.2 CDP 1350 1500
Charging, BC1.2 DCP 1100 1200
Charging, 5V non-USB 730 750
Charging, 12V non-USB 743 1000
Available Colors Twilight Black, Nova White, Healthcare White (DS8178-HC)
