Zebra DS8178 Product Reference Guide

13 - 6 DS8178 Digital Scanner Product Reference Guide
IDC Symbology
Parameter Name: DocCap_SYMBOLOGY
Parameter # 655 (SSI # F1h 8Fh)
Select the bar code type(s) to use when Document Capture mode is not set to Off. To enable more than one
symbology at a time, simply add the values together. For example, to enable PDF417, Data Matrix, and Code 39
write a value of 98 (32 + 64 + 2).
Scan the bar code below, followed by three bar codes from Appendix G, Numeric Bar Codes in the range of 000 to
255 decimal. The default is 001.
Table 13-2 IDC Symbologies
Symbology Value (Decimal)
Code 128 1
Code 39 2
I 2 of 5 4
D 2 of 5 8
Codabar 16
PD 417 32
Data Matrix 64
EAN 128 128
IDC Symbology

Zebra DS8178 Specifications

General

Product color	Black
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Photo diode
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Optical sensor resolution	1280 pixels
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
PC connection	RS-232/USB
Wireless range	100 m
Bluetooth version	4.0
Standard interfaces	USB, RS-232, Bluetooth
Connectivity technology	Wired & Wireless
Battery life	83 h
Battery capacity	2500 mAh
Power source type	Battery

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	235.3 g
