Symbologies 12 - 77

US Planet

Parameter # 90 (SSI # 5Ah)

To enable or disable US Planet, scan the appropriate bar code below.

Transmit US Postal Check Digit

Parameter # 95 (SSI # 5Fh)

Select whether to transmit US Postal data, which includes both US Postnet and US Planet, with or without the

check digit.

Enable US Planet

(1)

*Disable US Planet

(0)

*Transmit US Postal Check Digit

(1)

Do Not Transmit US Postal Check Digit

(0)
