Zebra DS8178 Product Reference Guide

7 - 12 DS8178 Digital Scanner Product Reference Guide
Optional USB Parameters
If you configure the imaging imager scanner and find the settings were not saved, or changed, when the system is
restarted scan the bar codes that follow to override USB interface defaults.
Scan a bar code below after setting defaults and before configuring the imaging imager scanner.
Ignore Beep
The host can send a beep request to the imaging imager scanner. When this parameter is enabled, the request is
not sent to the attached imaging imager scanner. All directives are still acknowledged to the USB host as if it were
processed.
Ignore Bar Code Configuration
The host has the ability to enable/disable code types. When this parameter is enabled, the request is not sent to
the attached imaging imager scanner. All directives are still acknowledged to the USB host as if it were processed.
Disable
*Enable
Disable
*Enable

Zebra DS8178 Specifications

General

Product color	Black
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Photo diode
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Optical sensor resolution	1280 pixels
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
PC connection	RS-232/USB
Wireless range	100 m
Bluetooth version	4.0
Standard interfaces	USB, RS-232, Bluetooth
Connectivity technology	Wired & Wireless
Battery life	83 h
Battery capacity	2500 mAh
Power source type	Battery

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	235.3 g
