Zebra DS8178 Product Reference Guide

USB Interface 7 - 3
USB Parameter Defaults
Table 7-1 lists the defaults for USB host parameters. If any option needs to be changed, scan the appropriate bar
code(s) provided in the Parameter Descriptions section beginning on page 7-4.
NOTESSee Appendix A, Standard Parameter Defaults for all user preferences, hosts, symbologies, and
miscellaneous default parameters.
See Appendix B, Country Codes for USB Country Keyboard Types (Country Codes).
Table 7-1 USB Host Default Table
Parameter Default
Page
Number
USB Host Parameters
USB Device Type HID Keyboard Emulation 7-4
Symbol Native API (SNAPI) Status Handshaking Enable 7-6
USB Keystroke Delay No Delay 7-6
USB CAPS Lock Override Disable 7-7
USB Ignore Unknown Characters Send 7-7
USB Convert Unknown to Code 39 Disable 7-8
Emulate Keypad Enable 7-8
Emulate Keypad with Leading Zero Enable 7-8
Quick Keypad Emulation Enable 7-9
USB FN1 Substitution Disable 7-9
Function Key Mapping Disable 7-10
Simulated Caps Lock Disable 7-10
Convert Case No Case Conversion 7-11
USB Static CDC Enable 7-11
Ignore Beep Enable 7-12
Ignore Bar Code Configuration Enable 7-12
USB Polling Interval 3 msec 7-14
USB Fast HID Enable 7-15
IBM Specification Version Version 2.2 7-15

Zebra DS8178 Specifications

General

Product color	Black
Housing material	-
International Protection (IP) code	IP42
Type	Handheld bar code reader
Wavelength	617 nm
Sensor type	Photo diode
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 60 °
Optical sensor resolution	1280 pixels
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
PC connection	RS-232/USB
Wireless range	100 m
Bluetooth version	4.0
Standard interfaces	USB, RS-232, Bluetooth
Connectivity technology	Wired & Wireless
Battery life	83 h
Battery capacity	2500 mAh
Power source type	Battery

Weight and Dimensions

Depth	107 mm
Width	66 mm
Height	168 mm
Weight	235.3 g
