Zebra ZD410 User Manual

USB Host Port and Link-OS Usage Examples
104
Using the USB Host Port and the NFC Capabilities
The Zebra Print Touch ™ feature allows you to touch an Android ™ -based, Near Field Communication
(NFC)-enabled device such as a smart phone or tablet to the printer’s Print Touch logo to pair the device to
the printer. This capability allows you to use your device to provide information for which you are prompted
and then print a label using that information.
This feature is not supported by all printer configurations. Only printers with the Print Touch logo have this
feature.
Important • Some mobile devices may not support NFC communication with the printer until you configure the
required NFC settings in your device. If you encounter difficulties, consult your service provider or your smart device
manufacturer for more information.
Print Touch Location
(Passive NFC)

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
