Zebra ZD410 User Manual

122
Troubleshooting
This section provides troubleshooting procedures and information.
Resolving Alerts and Errors
Alert: Printhead Open
A print command or a FEED button has been pressed and the printer has detected that the printhead
(cover) is not closed.
Possible Cause - 1
The cover is open or has not been closed properly.
Resolution
Close the cover/printhead. Push down on the front top corners of the printer’s cover. You should normally
hear and feel the cover latches snap in place to lock the cover closed for printing.
See Closing the printer.
Possible Cause - 2
The printer’s Head-Open switch needs service.
Resolution
Call a service technician.

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
