USB Host Port and Link-OS Usage Examples
99
USB Host and Printer Usage Examples
The exercises in this section will teach you how to perform USB mirror (using an alternate firmware update
procedure), how to transfer files to and from the printer, and how to provide information for which you are
prompted and then print a label using that information.
Items Required for the USB Host Exercises
To perform the exercises in this document, you will need the following:
• USB Flash drive up to 1 Terabyte (TB). The printer will not recognize drives larger than 1 TB.
• USB keyboard.
• Various files referenced below (from files attached inside this PDF file)
• Free Zebra Utilities app for your smart phone (search for Zebra Tech in the Google Play store).
Files for Completing the Exercises
Most of the actual files that you need to complete the exercises in these section are attached here in the
PDF file. Copy these files to your computer before you begin the exercises. Where possible, the contents
of the files are shown. The contents of files that contain coded content, which cannot be viewed as text or
as an image, are not included.
File 1: ZEBRA.BMP
File 2: SAMPLELABEL.TXT
This simple label format prints the Zebra logo and a line of text at the end of the mirroring exercise.
File 3: LOGO.ZPL
Uses the Zebra logo bitmap file.
^XA
^FO100,75^XGE:zebra.bmp^FS
^FO100,475^A0N,50,50^FDMirror from USB Completed^FS
^XZ

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
