Zebra ZD410 User Manual

Print Operations
86
Using the Label Dispenser Option
The label dispenser option allows you to print a label and have the backing material (liner/web)
automatically removed. When printing multiple labels, removing the dispensed (peeled) label triggers the
printer to print and dispense the next label.
To use dispenser-mode, set ‘Media Handling’ to ‘Peel-Off’ in the printer driver or with the Zebra Setup
Utility using the ‘Configure Printer Settings’ wizard. Otherwise, you must send the ZPL programming
commands to the printer.
When programming in ZPL, you can use the command sequences shown below to configure the printer
to use the dispenser option:
^XA ^MMP ^XZ
^XA ^JUS ^XZ
1. Load your labels into the printer. Close the printer and press the Feed button until a minimum of
100 millimeters or 4 inches of exposed labels exit the printer. You can leave the labels on the liner.

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
