Zebra ZD410 User Manual

Print Operations
96
Setting the Power Failure Recovery Mode Jumper
The printer can be configured to re-start itself after a power failure, unattended, with Power Failure
Recovery Mode.
Note • The Power Failure Recovery Mode is only available on printers with a Printer Connectivity Module installed in
your printer.
The Printer Connectivity Modules have a Power Failure Recovery jumper set to OFF. With the jumper set
to ON, the printer will automatically Power ON when plugged into an active (ON) AC power source (and
not power off).
ESD Caution • The discharge of electrostatic energy that accumulates on the surface of the human body or other
surfaces can damage or destroy the printhead or electronic components used in this device. You must observe
static-safe procedures when working with the printhead or the electronic components.
Setting the Jumper
1. Disconnect the DC power plug and any interface connectors from the rear of the printer.
2. Remove the module access door and connectivity module. See Removing Printer Connectivity
Modules for instructions for ZD410 printer models.
3. Move the AUTO (Power Failure Recovery Mode) jumper from the OFF position to the ON.
4. Reinstall the connectivity module and module access door. See Installing the Internal Ethernet (LAN)
Module or Installing the Serial Port Module for ZD410 printer models.
Reconnect the printer DC power plug and interface cables to the printer.

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
