Zebra ZD410 User Manual

Troubleshooting
126
Alert: PRINTHEAD UNDER TEMP
1. The printhead is below operating temperature for proper printing.
Possible Cause - 1
The ambient temperature at the printers location is below the specified operating range.
Resolution
Turn the printer off. Move the printer location and wait for it to warm naturally. Moisture may condense in
and on the printer if the temperature changes too quickly.
Possible Cause - 2
The printhead thermistor has failed.
Resolution
1 — Turn the printer off by holding the power using the POWER button down for 5 seconds. Wait for thee
printer to shutdown completely. Turn the printer on.
2 — If the printer does not recover from this error, call a service technician.

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
