Zebra ZD410 User Manual

Setup for Windows OS
74
Connecting the Printer to a Windows 8
Before adding (also called pairing) a Bluetooth enabled device, make sure it is turned on and discoverable.
As stated in the previous section under Connecting to a Windows Vista® SP2 or Windows 7® Master
Device, your Windows device may need a Bluetooth adapter to connect to Bluetooth device. Check with
your device manufacturer’s User Manual for further information.
1. Swipe in from the right edge of the screen or move your mouse towards the right edge of the screen,
select Settings, and then select Change PC Settings.
.
2. Select PC and devices, and then select Bluetooth. Once Windows displays the Bluetooth-enabled
devices, select the device and click Pair.
Note • Windows will display the pairing code for only 10 seconds, so complete this step quickly!
3. Follow the instructions on your screen to finish pairing your device.

Zebra ZD410 Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Maximum print height	991 mm
Maximum printing width	56 mm
Flash memory	512 MB
Internal memory	256 MB
Built-in barcodes	1D, 2D
Page description languages	EPL, EPL2, XML, ZPL, ZPL II
Display	-
Product color	Gray
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 41 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Core diameter	12.7 mm
Media thickness	0.08 - 0.305 mm
Maximum roll diameter	127 mm
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	220 mm
Width	115 mm
Height	151 mm
Weight	1000 g
